Oil Pan, GM LT, Swap, Spin-On Oil Filter Adapter

In stock
Part #
20155
$775.26
Chevrolet GM LT Series, Rear Sump Swap Aluminum, Wet Sump, 5 Quart Capacity, 5-7 8" Deep, 8-5 8" Wide, 8-1 2" Long Engine Application: GM LT Series Fits: L T Engine Conversions that require a Rear Sump (Check Measurements)

Aluminum, Wet Sump, 5 Quart Capacity 5-7/8" Deep, 8-5/8" Wide 8-1/2" Long

Engine Application:GM LT Series

Fits: LT Engine Conversions that require a Rear Sump (Check Measurements)

  • Due to the O.E.M. GM LT oil pans having the oil pump pickup built into the oil pan, our LT oil pan has a thick billet aluminum O-ringed rail incorporates a removable pick up, a billet front sump and a location to mount our billet aluminum spin-on oil filter adapter
  • Fabricated aluminum construction is more adaptable to add fittings, change finishes and weighs less than cast aluminum construction
  • Front of the oil pan is 1-7/8" deep to the beginning of the 5-7/8" Deep, 8-5/8" Wide, and 8-1/2" Long sump
  • Features a trap door baffle and a removable windage tray that wraps around the oil pump pick up for horsepower savings and oil control
  • Includes a billet aluminum adapter that allows a 22mm thread Moroso No. 22463 Racing or O.E.M. oil filter to be mounted in the stock location, no need to run a remote oil filter
  • For dipstick, use GM part No.12643278 dipstick and GM part No.12652951 dipstick tube

To Purchase this product please go to Related Products below.

Part No. Available Options
22463 Oil Filter, Moroso Racing
